FREE-WILi Multi Tool Device

Use Cases

I2C USB interface

SPI USB interface

UART USB interface

USB attached screen and buttons

Uart based protocol tool support

TPMS fuzzer or simulator

Keyless Entry simulator/monitor

Cybersecurity penetration testing

Development platform that is 80% done

Learning platform for Embedded Systems

Free_WiLi

Features

SPI, I2C, PIO, and UART available on GPIO

3 USB interfaces (Integrated HUB with 2 FS, 1 HS) for communication and power

11 GPIO Programmable voltage level for 1.1 to 5.5V with 24ma@3V or 32ma @5v (sn74lxc1t45)

2 GPIO for I2C voltage level between 0.9V to 5.5V with software enabled 10K pulls (PCA9517)

GPIO front end includes ICE40UP5k FPGA with 8MByte SRAM and High Speed USB (FT232H)

Two SMA connectors for antenna for longer range

320 x 240 Color Display

5 User configurable buttons

7 Full color LEDs

IR transmitter and receiver

Digital Speaker and Microphone

Raspberry Pi Pico (RP2040) Open Micro Platform for specific applications or custom code

Orca modules plug into GPIO header allows expansion for specific use cases

IO App firmware allows exercising all IO, USB Host API and Standalone scripting

16 Mbyte x 2 on board storage (22 MByte usable)

1000 ma Lithium ION battery with integrated charger

Real Time Clock (RTC)

Accelerometer
